•  4 kW (5.44 hp) Rated / 9.6 kW (13 hp) Peak
•  6 kW (8.20 hp) Rated / 12.46 kW (16.95 hp) Peak
• 10 kW (13.60 hp) Rated / 22.43 kW (30.50 hp) Peak

• Lead-Acid Battery Package 8x6V (11.52 kWh)
• Lithium Battery Package ( (10.8 kWh - 5.4 kWh)

Lead-Acid Battery Package

• Onboard Charge Unit
  95-220 VAC@6A 48V / 18A

Lithium Battery Package

• 3.3 kW Onboard Charge Unit
  220 VAC@16 A 48V / 50A
• 1 kW Onboard Charge Unit
  95-220 VAC@6A 48V / 18A (Only available at 5.4 kW)

CURTIS (350 A-600 A)

24 km/h - 50 km/h*

8 km/h

• Lead-Acid Battery Package: 80 km**
• Lithium Battery Package (10.8 kWh): 80 km**
• Lithium Battery Package (5.4 kWh): 40 km**

25%

Lead-Acid Battery Package
%80 - 7 hrs
%100 - 9 hrs
Lithium Battery Package (10.8 kWh)
%80 - 4 hrs
%100 - 6 hrs
Lithium Battery Package (5.4 kWh)
%80 - 2 hrs
%100 - 3 hrs

4.3 m

Reduced rotating, self-compensating, no need of lubricating
rack and pinion type helical gear steering box

Fully independent MacPherson style strut suspension

Semi independent, swing arm with coil springs over hydraulic shock absorbers

Naturally colored Thermoplastic ABS
White, Midnight Blue, Red, Black, Gray

Automotive style steel frame with high corrosion resistance
Sanding /E-coating/ Static Wet Paint

Self adjusting mechanical, rear wheel drum brakes and
regenerative braking
Option: 4-wheel hydraulic drum brake system

Foot actuated multi-lock parking brake
Option: Electromagnetic parking brake*

Lead-Acid Battery Package: 645 kg*
Lithium Battery Package: 510 kg*

• 1+3 Passenger
• 1+5 Passenger

600 kg

1000 kg

18 x 8.5-8 (6-ply Turf tyres)
20.5 x 8-10 (6 ply)
22 x 9.50-10 Off-Road Tyre**

2 years full warranty (Except wearable items)
5 years limited warranty (Motor and motor control unit)
70% performance @ min. 4000 cycles for lithium battery package
